KWP2000 Plus ECU REMAP Flasher driver (Q00553) KWP2000 Plus ECU REMAP Flasher. Downloads Manual KWP2000 Plus ECU REMAP Flasher driver. The KWP2000 Plus by GTE Performance - ECU flasher is designed to read and The simple and intuitive design makes the PS300 user friendly and easy. Apr 26, 2013 Functions of KWP2000 Plus. You can download 'KWP2000 Plus User Manual.pdf' and 'KWP2000 Plus Software.zip' on http://www.shopobd2.com/kwp2000-plus.

KWP2000 PLUS ECU Flasher OPERATION INSTRUCTIONS: Install driver: - Install the driver package to your notebook/pc. Connect the KWP2000 PLUS Flasher to a free USB port.

At the window, point to the folder where you installed the driver package. How to READ data from a supported ECU: - Connect the KWP2000 PLUS ECU Flasher to computer USB port and to the diagnostic port of the car - Start the communication software in the computer. Turn ignition key to “ON” position. (Do not crank or start the engine). Select the ECU type you want to read/write from the given list. Select additional options (if needed) - Click the READ button to read out the original data (where supported). Save the file to the Hard Disk, Edit or Forward it another folder How to WRITE data to a supported ECU: - Connect the KWP2000 PLUS ECU Flasher to computer USB port and to the diagnostic port of the car - Start the communication software in the computer.

Turn ignition key to “ON” position. (Do not crank or start the engine). Select the ECU type you want to read/write from the given list. Select additional options (if needed). Click the WRITE button and select the file you want to write - Follow the instructions on screen - Switch the ignition key to “OFF” position and wait for 10 seconds before starting the engine again. Reading the ECU EEPROM chip First choose the vehicle and type of the engine's ecu you want to read/write from the given list. If you have any doubt about the type of ECU, you can verify it from the program.

When the dialogue window appears just click on INFO tab and wait for the program to communicate with the ECU. 1 A moment later, the information about the ECU type will be shown. Just click on “READ” tab to assure that you will have a copy of the original file (in case there is some problem later). When the program starts reading the ECU’s chip, DO NOT INTERRUPT the process at this moment. Choose where you want to save the original file and name it. To simplify your work, name it same as the numbers that appear in the window display on “Information of the ECU”. Now the program will prompt you to turn the ignition key to “OFF” position.

Do as instructed and then click the “OK” button. 2 Writing into the ECU EEPROM chip Choose the vehicle and type of the ECU (as in the “READ” process) click on INFO tab.

OPEN the file prepared for your vehicle or ECU type. From the display, on the right window you will see the reference of the ECU that corresponds to the open file. To confirm that this information matches with our ECU type. Verify the numbers in both windows are the same just to be on the save side. If you are absolutely sure that everything you did is correct.

Click on PROG tab, the system will now erase the ECU flash memory and program it with the new file. Please DO NOT INTERRUPT during this process. When it had finished writing, just turn the ignition key to “OFF” position and then confirm by clicking the OK button. Wait for 10 seconds and it is done! Now you can enjoy the new ECU program. 3 NOTE: For some cases, VAG cars (AUDI, VOLKSWAGEN, SEAT AND SKODA) before attempting to flash the ECU chip, the instruments panel must be de-activated.

Open the fuse box cover; remove the 5A fuses as indicated in red (refer figure below). With the instruments panel power cut off you can try to access the ECU.

Kwp 2000 Plus Software Download

KWP2000 Plus is obd2 repair ECU Flash Programmer. KWP2000 Plus ECU Remap Flasher support Upgrad the ECU software. KWP2000 Plus ECU Flash Programmer can repair ECUs with software problems or corruption. KWP2000 Plus ECU Flash Programmer KWP2000 Plus ECU Remap Flasher KWP2000 Plus Compatible Car Brands For BMW, For Volkswagen, For Mercedes, For Ford, For Nissan, For Ferrari, For Hyundai, For Volvo, For Mini, For Izuzu, For Honda, For Kia, For Alfa Romeo, For Fiat, For Lancia, For Smart, For Cirtoen, For Peugeout, For Audi, For Seat, For Skoda, For Chrysler, For Opel, For Renault, For Rover KWP2000 Plus PDF download KWP2000 Plus specialty 1. KWP2000 Plus is obd2 repair ECU Flash Programmer which can read and analys your current ECU software. KWP2000 Plus ECU Remap Flasher support Upgrad the ECU software with a re-mapped file. KWP2000 Plus ECU Flash Programmer can repair ECUs with software problems or corruption.

How do you use the KWP2000 PLUS? 1.You need a computer. Installing KWP2000 Plus software. 2.Connect USB cable to your PC; 3.Connect to your car via standard 16-pin OBD2 connector; 4.Supports high speed ECU flashing 5.Led indications for USB-power Car-power/rx/tx 6.Support KWP2000+ software and other KWP/ ISO software How to Read and Write data with KWP2000 PLUS?
